Model

 LHFW-1-1300

 Cutting width

 20-1300mm

 Slitting thickness

 Stainless steel woven mesh diameter less than 0.3mm, other specifications can be customized.

 Slitting speed

 0-10 meters per minute

 Voltage

 380V

 Power

 1.5KW

 Standard Configuration

 Equipped with 10 sets of knives

 Model

 LHFW-1-1300

 Cutting width

 20-1300mm

 Slitting thickness

 Stainless  steel  woven  mesh  wire  diameter  less  than  0.3mm,  other specifications can be customized.

 Slitting speed

 0-50 meters per minute

 Voltage

 380V

 Power

 3.5KW

 Standard Configuration

 Equipped with 10 sets of knives

 Notes

 The equipment is equipped with a 3-inch air shaft and magnetic powder brake.

 Model

 LHFW-4-1300

 Cutting width

 20-1300mm

 Slitting thickness

 Stainless  steel  woven  mesh  wire  diameter  less  than  0.3mm,  other specifications can be customized.

 Slitting speed

 0-100 meters per minute

 Voltage

 380V

 Power

 5.5KW

 Standard Configuration

 Equipped with 12 sets of knives

 Notes

 3-inch air expansion shaft, magnetic powder brake, automatic winding of edge material.

 Model

 LHDW-1-1000

 Cutting width

 100mm-1000mm

 Cutting accuracy

 ±0.3mm

 Slitting speed

 0-30 times per minute

 Voltage

 380V

 Power

 3KW

 Standard Configuration

 /

 Notes

 PLC servo motor control to automatically set the cutting length, and has a flat mesh function for thicker mesh.

 LHDW-3-1250

 100mm-1250mm

 ±0.3mm

 0-30 times per minute

 380V

 3KW

 Equipped with 5 pairs of slitting knives

 PLC servo motor control to automatically set the cutting length, and has a flat mesh function for thicker mesh.

 Model

 LHFQ-1000

 Cutting width

 100mm-1000mm

 Cutting accuracy

 ±0.3mm

 Slitting speed

 0-30 times per minute

 Voltage

 380V

 Power

 5KW

 Standard Configuration

 /

 Notes

 Air expansion shaft, magnetic powder brake, automatic winding of edge material.
